Satco S11691 11W/15W Integrated LED CCT Selectable LED Light Bulb Integrated Base

Satco S11691 11W/15W Integrated LED CCT Selectable LED Light Bulb Integrated Base

SATCO
$25.95 USD
$25.95 USD
Sale Sold out
Shipping calculated at checkout.

CB-0279353
11/15 Watt; LED Direct Wire Downlight; 27K/3K/35K/4K/5K CCT; Remote Driver; 6 Inch; Round; Flat Face; White Finish; 120-277 Volt; Dual Dimming15WLED/DW/6/FS/RND/FL/DD (Satco S11691) — Commercial Fi... Show More
View full details

11/15 Watt; LED Direct Wire Downlight; 27K/3K/35K/4K/5K CCT; Remote Driver; 6 Inch; Round; Flat Face; White Finish; 120-277 Volt; Dual Dimming

15WLED/DW/6/FS/RND/FL/DD (Satco S11691) — Commercial Fixtures › Downlights › Direct Wire Downlights.

Specifications

Watts 11W/15W
Lumens 1050L/1350L
CCT (Kelvin Temp) 2700K/3000K/3500K/4000K/5000K
Color Temp Warm White to Natural Light
CCT Selectable Yes
Wattage Selectable Yes
CRI 90+
Volts 120V-277V
Amps 0.092-0.040/0.125-0.054A
Hours Rated 50000
Dimmable Yes-Dimmable
Dimming Type Dual Dimming, Forward (TRIAC) or Reverse Phase at 120V/0-10V at 120-277V
Beam Angle (degree) 108
Lamp Base Integrated
ANSI Base Integrated
Lamp Type Integrated LED
Product Technology LED
Incandescent Equivalent 85W
Fixture Type Remote Driver LED Downlight
Style Utility
Finish WHITE
Finish Family White
Material Aluminum
Lens Finish Matte Frosted
Lens Material Acrylic
Bulb Included Integrated
Indoor Outdoor Indoor and Outdoor
Location Rating Wet
Safety Listing cETLus - Listed
Operating Temp -4F to +104F (-20C to +40C)
Power Factor >0.9
Total Harmonic Distortion <20%
Surge Protection Built-in surge protection - 2.5KV
Warranty 5-Years
Web Width 6.77
Web Height 1.34
Title 20 Exempt
T24/JA8 Compliant Yes
California Ban Lawful for sale
UPC 045923116919
Case Quantity 12
Pack Type Box

S11691 Instructions (PDF) · Satco product page

Product Information

Part Number S11691
Brand SATCO
Product Code S11691
UPC 045923116919

Specifications

Technology LED
Wattage 11
Input Voltage 120V-277V
Color Temperature 2700K/3000K/3500K/4000K/5000K
Lamp Base Integrated
Lumens 1050.0
Hours 50000
CRI 90
Dimmable true
Beam Spread 108
