Nuvo 65-836 20 Watt LED 2 Foot Linear Vapor Proof Fixture, 3K/4K/5K CCT Selectable, 120-347 Volt
Nuvo 65-836 20 Watt LED 2 Foot Linear Vapor Proof Fixture, 3K/4K/5K CCT Selectable, 120-347 Volt
SATCO
Regular price
$122.99 USD
Regular price
Sale price
$122.99 USD
Shipping calculated at checkout.
Quantity
SKU:CB-0279113
Couldn't load pickup availability
20 Watt LED 2 Foot Linear Vapor Proof Fixture; 3K/4K/5K CCT Selectable; 120-347 Volt; Gray Finish2' LED EM LINEAR VAPOR PROOF (Nuvo 65-836) — Commercial Fixtures › Linear › Vapor Tights.Specificati...
Show More
20 Watt LED 2 Foot Linear Vapor Proof Fixture; 3K/4K/5K CCT Selectable; 120-347 Volt; Gray Finish
2' LED EM LINEAR VAPOR PROOF (Nuvo 65-836) — Commercial Fixtures › Linear › Vapor Tights.
Specifications
| Watts | 20W |
| Lumens | 2164L-2505L |
| CCT (Kelvin Temp) | 3000K/4000K/5000K |
| Color Temp | Soft White to Natural Light |
| CCT Selectable | Yes |
| Wattage Selectable | No |
| CRI | 80+ |
| Volts | 120V-347V |
| Amps | 0.167-0.058A |
| Hours Rated | 50000 |
| Dimmable | Yes-Dimmable |
| Dimming Type | 0-10V Dimming |
| Beam Angle (degree) | 120 |
| Lamp Base | Integrated |
| ANSI Base | Integrated |
| Lamp Type | Integrated LED |
| Product Technology | LED |
| Incandescent Equivalent | 125W |
| Fixture Type | Vapor Tight |
| Style | Utility |
| Finish | Gray |
| Finish Family | Gray |
| Material | Polycarbonate (PC) |
| Lens Finish | Opaque |
| Lens Material | Polycarbonate (PC) |
| Bulb Included | Integrated |
| Mounting Procedure | Ceiling/Wall |
| Indoor Outdoor | Indoor, Outdoor |
| Location Rating | Wet |
| IP Rating | IP65 |
| Safety Listing | cETLus - Listed |
| Operating Temp | -40F to +113F (-40C to +45C) |
| Power Factor | >0.96 |
| Total Harmonic Distortion | 10.30% |
| Surge Protection | Built-in surge protection - 2KV |
| Warranty | 5-Years |
| Web Length | 23.62 |
| Web Width | 4.84 |
| Web Height | 3.54 |
| Title 20 | Yes |
| T24/JA8 Compliant | No |
| California Ban | Lawful for sale |
| UPC | 045923403538 |
| Case Quantity | 6 |
| Pack Type | Kraft Box |
Product Information
Part Number
65-836
Brand
SATCO
Product Code
65-836
UPC
045923403538
Specifications
Technology
LED
Wattage
20
Input Voltage
120V-347V
Color Temperature
3000K/4000K/5000K
Lamp Base
Integrated
Lumens
2164.0
Hours
50000
CRI
80
Dimmable
true
Beam Spread
120
