Nuvo 65-1676 30/40/50 Wattage Selectable LED 2ft x 4ft Backlit Panel, 35K/4K/5K CCT Selectable, Emergency Battery
Nuvo 65-1676 30/40/50 Wattage Selectable LED 2ft x 4ft Backlit Panel, 35K/4K/5K CCT Selectable, Emergency Battery
SATCO
Regular price
$185.99 USD
Regular price
Sale price
$185.99 USD
Shipping calculated at checkout.
Quantity
SKU:CB-0279006
Couldn't load pickup availability
30/40/50 Wattage Selectable LED 2ft x 4ft Backlit Panel; 35K/4K/5K CCT Selectable; Emergency Battery; 120-347 Range Voltage; White Finish2X4 LED EM BACKLIT FLAT PANEL (Nuvo 65-1676) — Commercial Fi...
Show More
30/40/50 Wattage Selectable LED 2ft x 4ft Backlit Panel; 35K/4K/5K CCT Selectable; Emergency Battery; 120-347 Range Voltage; White Finish
2X4 LED EM BACKLIT FLAT PANEL (Nuvo 65-1676) — Commercial Fixtures › Troffers & Panels › Panels.
Specifications
| Watts | 30W/40W/50W |
| Lumens | 3750L/4500L/6250L |
| CCT (Kelvin Temp) | 3500K/4000K/5000K |
| Color Temp | Neutral White to Natural Light |
| CCT Selectable | Yes |
| Wattage Selectable | Yes |
| CRI | 80+ |
| Volts | 120V-347V |
| Amps | 0.080-0.420A |
| Hours Rated | 50000 |
| Dimmable | Yes-Dimmable |
| Dimming Type | 0-10V Dimming |
| Beam Angle (degree) | 120 |
| Lamp Base | Integrated |
| ANSI Base | Integrated |
| Lamp Type | Integrated LED |
| Product Technology | LED |
| Incandescent Equivalent | 250W |
| Fixture Type | Flat Panel |
| Style | Utility |
| Finish | WHITE |
| Finish Family | White |
| Material | Die-cast Aluminum |
| Lens Finish | White |
| Lens Material | Polystyrene (PS) |
| Bulb Included | Integrated |
| Mounting Procedure | Ceiling |
| Indoor Outdoor | Indoor |
| Location Rating | Damp |
| IP Rating | IP20 |
| Safety Listing | cULus - Certified |
| Operating Temp | +1.4F to +113F (-17C to +45C) |
| Power Factor | 0.9 |
| Total Harmonic Distortion | <20% |
| Surge Protection | Built-in surge protection - 2KV |
| Warranty | 5-Years |
| Web Length | 47.76 |
| Web Width | 23.74 |
| Web Height | 2.6 |
| Title 20 | Yes |
| T24/JA8 Compliant | No |
| California Ban | Lawful for sale |
| UPC | 045923411878 |
| Case Quantity | 1 |
| Pack Type | Box |
Product Information
Part Number
65-1676
Brand
SATCO
Product Code
65-1676
UPC
045923411878
Specifications
Technology
LED
Wattage
30
Input Voltage
120V-347V
Color Temperature
3500K/4000K/5000K
Lamp Base
Integrated
Lumens
3750.0
Hours
50000
CRI
80
Dimmable
true
Beam Spread
120
