LED Area Light; 300/240/200 Wattage Selectable; 3K/4K/5K CCT Selectable; Beam Angle Selectable; Bronze; 120-277 Volt
LED AREA LIGHT BRONZE 120-277V (Nuvo 65-1526) — Commercial Fixtures › Site & Area › Site & Area.
Specifications
| Watts | 300W/240W/200W |
| Lumens | 31048L-47341L |
| CCT (Kelvin Temp) | 3000K/4000K/5000K |
| Color Temp | Soft White to Natural Light |
| CCT Selectable | Yes |
| Wattage Selectable | Yes |
| CRI | 80+ |
| Volts | 120V-277V |
| Amps | 2.500-1.080/2.000-0.870/1.670-0.720A |
| Hours Rated | 50000 |
| Dimmable | Yes-Dimmable |
| Dimming Type | 0-10V Dimming |
| Beam Angle (degree) | 155x70/155x120/155x145 |
| Lamp Base | Integrated |
| ANSI Base | Integrated |
| Lamp Type | Integrated LED |
| Product Technology | LED |
| Incandescent Equivalent | 1500W-2500W |
| Fixture Type | Area Light |
| Style | Utility |
| Finish | BRONZE |
| Finish Family | Bronze |
| Material | Die-cast Aluminum |
| Lens Finish | Clear |
| Lens Material | Polycarbonate (PC) |
| Bulb Included | Integrated |
| Indoor Outdoor | Outdoor |
| Location Rating | Wet |
| IP Rating | IP65 |
| Safety Listing | cULus - Listed |
| Operating Temp | -40F to +122F (-40C to +50C) |
| Power Factor | >0.9 |
| Total Harmonic Distortion | <20% |
| Surge Protection | Built-in surge protection - 6KV |
| Warranty | 5-Years |
| Web Length | 29.2 |
| Web Width | 14.0 |
| Web Height | 3.2 |
| Title 20 | Exempt |
| T24/JA8 Compliant | No |
| California Ban | Lawful for sale |
| UPC | 045923412554 |
| Case Quantity | 1 |
| Pack Type | Brown Box |
65-1526 EPA Rating Report (PDF) · 65-1526 Instructions (PDF) · 65-1526 Spec Chart (PDF) · Satco product page
Product Information
Part Number
65-1526
Brand
SATCO
Product Code
65-1526
UPC
045923412554
Specifications
Technology
LED
Wattage
300
Input Voltage
120V-277V
Color Temperature
3000K/4000K/5000K
Lamp Base
Integrated
Lumens
31048.0
Hours
50000
CRI
80
Dimmable
true
Beam Spread
155
