Nuvo 65-1322 50/40/30 Watt LED 2x4 Flat Panel Troffer Retrofit Kit, 35K/4K/5K CCT, Dimmable
Nuvo 65-1322 50/40/30 Watt LED 2x4 Flat Panel Troffer Retrofit Kit, 35K/4K/5K CCT, Dimmable
SATCO
Regular price
$87.99 USD
Regular price
Sale price
$87.99 USD
Shipping calculated at checkout.
Quantity
SKU:CB-0278928
Couldn't load pickup availability
50/40/30 Watt LED 2x4 Flat Panel Troffer Retrofit Kit; 35K/4K/5K CCT; Dimmable; 120-277 Volt; Matte White Finish2X4 FLAT PANEL RETROFIT (Nuvo 65-1322) — Commercial Fixtures › Troffers & Panels ...
Show More
50/40/30 Watt LED 2x4 Flat Panel Troffer Retrofit Kit; 35K/4K/5K CCT; Dimmable; 120-277 Volt; Matte White Finish
2X4 FLAT PANEL RETROFIT (Nuvo 65-1322) — Commercial Fixtures › Troffers & Panels › Retrofits.
Specifications
| Watts | 50W/40W/30W |
| Lumens | 5500L/4400L/3300L |
| CCT (Kelvin Temp) | 3500K/4000K/5000K |
| Color Temp | Neutral White to Natural Light |
| CCT Selectable | Yes |
| Wattage Selectable | Yes |
| CRI | 80+ |
| Volts | 120V-277V |
| Amps | 0.417-0.181/0.333-0.144/0.250-0.108A |
| Hours Rated | 50000 |
| Dimmable | Yes-Dimmable |
| Dimming Type | 0-10V Dimming |
| Beam Angle (degree) | 120 |
| Lamp Base | Integrated |
| ANSI Base | Integrated |
| Lamp Type | Integrated LED |
| Product Technology | LED |
| Incandescent Equivalent | 125W |
| Fluor Equiv | 3 x 32W T8 |
| Fixture Type | Troffer |
| Style | Utility |
| Finish | Matte White |
| Finish Family | White |
| Material | Steel |
| Housing Color | Matte White |
| Lens Finish | Frosted |
| Lens Material | Polystyrene (PS) |
| Bulb Included | Integrated |
| Mounting Procedure | Ceiling |
| Indoor Outdoor | Indoor |
| Location Rating | Damp |
| IP Rating | IP20 |
| Safety Listing | cETLus - Classified |
| Operating Temp | -4F to +104F (-20C to +40C) |
| Power Factor | >0.9 |
| Total Harmonic Distortion | <20% |
| Surge Protection | Built-in surge protection - 2KV |
| Warranty | 5-Years |
| Web Length | 47.81 |
| Web Width | 23.82 |
| Web Height | 2.03 |
| Title 20 | Exempt |
| T24/JA8 Compliant | No |
| California Ban | Lawful for sale |
| UPC | 045923411403 |
| Case Quantity | 1 |
| Pack Type | Kraft Box |
Product Information
Part Number
65-1322
Brand
SATCO
Product Code
65-1322
UPC
045923411403
Specifications
Technology
LED
Wattage
50
Input Voltage
120V-277V
Color Temperature
3500K/4000K/5000K
Lamp Base
Integrated
Lumens
5500.0
Hours
50000
CRI
80
Dimmable
true
Beam Spread
120
